1. Main advantages of this machine

● Automatic facial tissue packing machine is high speed fully automatic napkin wrapping machine is suitable for automatically packing V/M fold tissue,napkin and flat tissue.

● This machine adopts 11 sets servos for controlling the movements,they are main pusher,paper feeding,film pulling,film cutting,perforation,paper center sending,paper forwarding,package pressing,dynamic edge guides,siding sealing sewing,side seal lift up & down,film folding lift up & down.With advantages of complete operation configuration,high efficiency,easily operation,wide size applicable range,quick for side changeover,convenient for maintenance,low cost for using etc.

● Functions of the machine:1 )Paper sorting 2 )Avoid bad block feeding 3)Electric inching correction function 4)Auto speed decline when not paper 5)Paper length error protection function 6)Paper width error protection function 7)High temperature resistance belt protection function 8)paper output healing & cooling sectional sealing device.

● Stable production speed:30-60 packs/min

2. Machine Pictures

3. Packing style

Packing style and dimension

Single pack style	Twin pack style

4. Packing flow chart

5. Technical parameters and features:

6.Main electrical component,temperature control component,pneumatic component and transmission component.

6.1. Power consumption of each part:

7. List of common spare part with machine

8、Acceptance Standard：

8.1 Tested products dimension: Length mm、Width mm、Height mm.Tolerance paper length and width ≤2mm, height ≤10mm，packaging material:CPP,thickness≥0.04mm.

8.2 Finished product qualified standard: Even for the sealed parts,over heat part ≤5mm，date of manufacturer,batch number etc are printed clearly. Misalignment ≤±2mm.

8.3 Assurance production speed: 50 packs/min for single pack; Upstream infeed speed should fulfill the multipack wrapper speed, or the upstream down time would not be taken into account.

8.4 Packing efficiency: ≥85% . test production time：4hrs. (Excluding reel changeover time or down time or idle running time that NOT caused by the machine’s own performance). Products quantity should be counted before the test run. And after the test, defects would be counted to calculate the qualification rate.

8.5 Qualification rate: ≥97% . Defects products that are due to tissue oversize, unqualified packing film or dis operation by the buyer workers would not be counted.
